The wings on the A5 can be folded for storage or trailering (on an Icon designed trailer). The process takes about 30 seconds per wing to fold or unfold. We watched a first-timer take a minute to unfold a wing and lock it into position. To fold, a latching handle in the wing root is unlatched, the wing is pulled outboard via a handle at the tip, then rotated 90 degrees, moved aft 90 degrees and attached to the horizontal stabilizer inboard of its removable tip. To unfold, the process is reversed. The attachment latch will only lock if the wing is lined up correctly. The ailerons and flaps connect automatically through cam-type pushrod connections.
